ProFire TL-225 Tilting Electric Crucible Furnace – 700 lb Red Brass Capacity

The ProFire TL-225 Tilting Electric Crucible Furnace is a heavy-duty industrial melting furnace designed for foundries, metalworking facilities, refining operations, manufacturing environments, and other high-volume non-ferrous metal melting applications. Equipped with a large #225 crucible and an approximate 700 lb red brass capacity, this electric furnace provides the capacity, temperature control, and pouring capabilities required for demanding professional operations.

Featuring automatic temperature controls with a digital readout, the ProFire TL-225 allows the operator to select the desired operating temperature while the control system maintains the set point throughout the melting process. This provides consistent temperature management for large-volume melts and repeated production cycles.

The furnace utilizes a heavy-wall #225 clay-graphite crucible with an integrated pouring spout. The stated 700 lb capacity is based specifically on red brass; actual metal capacity will vary depending on the density and type of alloy being melted.

Controlled Tilting & Pouring

Designed to simplify the handling of large quantities of molten metal, the ProFire TL-225 features an integrated tilting design with a backing winch for precise and controlled movement during pouring.

Rather than requiring the operator to manually remove a large crucible filled with molten metal, the entire furnace can be tilted to pour directly from the crucible's integrated spout.

A vented lid provides convenient access to the crucible and securely latches in the raised position during loading and operation.

Key Features

• Approximate 700 lb Red Brass Capacity
• #225 Crucible: Heavy-wall clay-graphite construction with integrated pouring spout
• Automatic Temperature Control: Maintains the temperature selected by the operator
• Digital Temperature Readout: Provides convenient temperature monitoring throughout the melting process
• Tilting Furnace Design: Allows controlled pouring directly from the furnace
• Backing Winch: Provides precise control over furnace movement during pouring
• Vented Latching Lid: Securely latches in the raised position for convenient crucible access
• Insulating Firebrick Lining: Helps maximize heat retention and operating efficiency
• Heavy-Duty Construction: Built for demanding industrial and production environments
• Electric Heating: Provides controlled heating without the need for a fuel-fired burner system
• Made in the USA

Specifications

Industrial High-Capacity Metal Melting

With an approximate 700 lb red brass capacity, the ProFire TL-225 bridges the gap between medium-capacity tilting furnaces and larger industrial melting systems. Its combination of a substantial #225 crucible, automatic temperature management, heat-retaining insulation, and controlled tilting system makes it an excellent choice for facilities processing significant quantities of non-ferrous metals.

The tilting configuration provides controlled pouring while the heavy-wall clay-graphite crucible, insulating firebrick lining, and rugged furnace construction are designed for the demands of professional melting operations.

Metal capacity will vary according to the alloy and its density. The stated 700 lb capacity is based specifically on red brass.

Made to Order & Freight Shipping

The ProFire TL-225 is made to order. Please allow an approximate 1–2 week lead time for production.
